Specifications
Kilowatt | 8 kW |
Length (L.1) | 500 mm |
Mount Hole Center - Center (O.1) | 126.5 mm |
Mount Hole Center - Center (O.2) | 126.5 mm |
Mount Hole Center - Center (O.3) | 126.5 mm |
Mount Hole Diameter (C.1) | 16.5 mm |
Mount Hole Diameter (C.2) | 16.5 mm |
Mount Hole Diameter (C.3) | 16.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
Oil Sealed | Yes |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | DELCO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CASE | 35D | [4-53] | 01.1986-12.1999 |
CASE | 40D | [4-53] | 01.1986-12.1986 |
CASE | 40DR | [4-53] | 01.1985-12.1994 |
CASE | 40LC | [4-53] | 01.1986-12.1986 |
CASE | 40LC | [4-53] | 01.1986-12.1995 |
CASE | 40R | [4-53] | 01.1986-12.1986 |
CASE | 40R | [4-53] | 01.1986-12.1995 |
CASE | 50D | [4-53] | 01.1986-12.1986 |
CATERPILLAR | 815F | [3176] | 01.1996-12.2008 |
CATERPILLAR | 816F | [3176C] | 01.2000-12.2005 |
CATERPILLAR | Engine | [19450] | 01.1986-12.1998 |
Reference Information
0R6657 6381N OR7757 10R8909 1740620 12309841 91-01-4290 10461026 641.005.133.519 10514693 1654619 0R7757 1993786 641.005.133.030 140-42865 1993923 6060632 2175214 UD21050S 2517593 TS-1571 20409236BN 2906527 10461137 40461137 8200755 1990435 10479253 Y10E06 CST60632ASVideo/Publications
UD21050S 641.005.133.519 641.005.133.030 0R6657 0R7757 1654619 1740620 2175214 2517593 10514693 10479253 CST60632AS 20409236BN 6060632.0 10R8909 2906527 OR7757 Y10E06 91-01-4290 140-42865 10461026 10461137 12309841 1990435 1993786 1993923 40461137 8200755 6381N TS-1571Add Your Number
