Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HYUNDAI / KIA
Price:
NZ$ 222.63 including GST
NZ$ 193.59 excluding GST
or four payments of $55.66
with
Learn More
each
SGV-C10043
S9429S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
36100-03101Associated Numbers
0986026300 Bosch ruil 116260 Cargo 1201952 Valeo show 201952 250515102 PSH 255062 Elstock 26024598A Lucas 3610003101 Kia 3610003401 3610004300 Hyundai 3610004700 3610004800 600275 911281 Remy DRS1281 F002GC0001 F002GC0050 F002GC0051 JM000A18801 LRS03899 LRS3899 RNL3610003101 RNL S0001201952 STR71375 Wood Auto VAL600275 WOOSTR71375 Exchange 10438365 Alanko 220780 Messmer 250515102SEL +line 30592N WAI 30592OS 324090102 DRI 336044 Logistik 438365 88214730 Power Max AEX1386 Electro AEY3899 AS2758AC Charge CGB23265 Ainde CST32148 Airframe IR9951 Protech NSM1732 Napa (UK) S000V201952 S132044 Short code S143847 S164471 S9429 AS-PL S9429S SVA1127 Quasar SXE1026 Everkraft SXE1026ESpecifications
| Kilowatt | 0.90 kW |
| Length (L.1) | 185 mm |
| Mount Hole Center - Center (O.1) | 99 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 14 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | HYUNDAI / KIA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | i10 1.2 | [G4LA] | 12.2013- |
| HYUNDAI | i20 1.2 | [G4LA] | 11.2014- |
| HYUNDAI | i20 1.2 Coupe | [G4LA] | 05.2015- |
| HYUNDAI | i20 1.2 LPG Elite | [G4LA] | 01.2019- |
| HYUNDAI | i20 1.2 MPi | [G4LA] | 05.2015- |
| KIA | Rio 1.2 | [G4LA] | 09.2011-12.2017 |
| KIA | Rio 1.2 | [G4LA] | 11.2014-12.2017 |
| KIA | Rio 1.2 CVVT | [G4LA] | 04.2015-12.2017 |
| KIA | Rio 1.2 CVVT | [G4LA] | 09.2011-12.2017 |
| KIA | Rio 1.2 CVVT | [G4LA] | 10.2011-12.2017 |
| KIA | Rio 1.2 LPG | [G4LA] | 09.2011- |
Reference Information
| 116260 | CARGO |
| 1201952 | VALEO |
| 20493841OE | REAL |
| 220780 | ERA |
| 250.515.102.120 | PSH |
| 250.515.102.130 | PSH |
| 250.515.102.265 | PSH |
| 250.515.102.360 | PSH |
| 25-5062 | ELSTOCK |
| 255537V | KUHNER |
| 26024598 | LUCAS |
| 2S0490R | RIDEX |
| 30592N | WAI / TRANSPO |
| 336044 | LOGISTIK |
| 36100-03101 | HYUNDAI / KIA |
| 36100-03201 | HYUNDAI / KIA |
| 36100-03401 | HYUNDAI / KIA |
| 36100-03402 | HYUNDAI / KIA |
| 36100-04300 | HYUNDAI / KIA |
| 36100-04700 | HYUNDAI / KIA |
| 600275 | VALEO |
| 6032148.1 | SANDO |
| 88214730 | POWERMAX |
| 9589 | CEVAM |
| AEY3899 | AUTOELECTRO |
| ASM1732 | APEC |
| BN3610003101 | MANDO |
| CGB-23265 | AINDE |
| CGB-55062 | AINDE |
| CST25135GS | CASCO |
| CST32148GS | CASCO |
| F002GC0051 | BOSCH |
| F032116260 | CARGO |
| J5210537 | HERTH+BUSS |
| JM000-A18801 | HYUNDAI / KIA |
| LRS03899 | LUCAS |
| LRS3899 | LUCAS |
| MAV341480 | SIOM |
| NPANSM1732 | NAPA |
| PRSE430 | 3EFFE |
| S0001201952 | MANDO |
| S000K201952 | MANDO |
| S9429S | AS-PL |
| STR00186 | ELECTROLOG |
| STR71375 | WOODAUTO |
| STRE430 | 3EFFE |
| STV1830 | KRAUF |
| STX200921 | STARDAX |
| STX200921R | STARDAX |
| STX200922 | STARDAX |
| STX200922R | STARDAX |
| STX210281 | STARDAX |
| STX210281R | STARDAX |
| UD19276S | AS-PL |
Video/Publications
