Associated Numbers
0001147400 0001147401 0986023100 25-4241 254727 2769061200 2769062300 276906230080 3211 550.552.102 6519061200 88214629 91-15-7343 A2769061200 A2769062300 A276906230080 A6519061200 BOS0001147400 DRS0732 IM3162 LRS02569 UD12704S UNIT BOM 120-6530
701322 70-1322
0001147400 Bosch show SGB-C10001
0001147400SEL +line
0986023100 Bosch ruil
0986023107 Bosch ruil
107721 FARC
11090380 EuroTec
2769062300 Mercedes-Benz
550552102 PSH
8080328 Friesen
8080328F Friesen
910732 EDR
A2769061200 Mercedes-Benz
A2769062300 Mercedes-Benz
DRS0732 Remy
LRS02569 Lucas
OSM11948 Optimum
SR0499N Bosch (USA)
SR0499X Bosch (USA)
70-1322
Specifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 249 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 27 mm |
| Rotation | CW |
| Spigot Diameter (A) | 60 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | C 300 3.5 | (W204)[M276.957] | 02.2011-01.2014 |
| MERCEDES BENZ | C 300 3.5 4-Matic | (W204)[M276.957] | 02.2011-01.2014 |
| MERCEDES BENZ | C 350 3.5 | (W204)[M276.957] | 01.2011-01.2014 |
| MERCEDES BENZ | C 350 3.5 4-Matic | (W204)[M276.957] | 01.2011-01.2014 |
| MERCEDES BENZ | C 350 3.5 CGi | (S204)[M276.957] | 06.2011-08.2014 |
| MERCEDES BENZ | CLS 350 3.5 | (C218)[M276.952] | 01.2011- |
| MERCEDES BENZ | E 300 3.5 | (A207)[M276.957] | 04.2011- |
| MERCEDES BENZ | E 300 3.5 | (C207)[M276.957] | 04.2011- |
| MERCEDES BENZ | E 300 3.5 | (S212)[M276.952] | 07.2011- |
| MERCEDES BENZ | E 300 3.5 | (W212)[M276.952] | 07.2011- |
| MERCEDES BENZ | E 350 3.5 | (A207)[M276.957] | 04.2011- |
| MERCEDES BENZ | E 350 3.5 | (C207)[M276.957] | 04.2011- |
| MERCEDES BENZ | E 350 3.5 | (S212)[M276.952] | 09.2011- |
| MERCEDES BENZ | E 350 3.5 | (W212)[M276.952] | 09.2011- |
| MERCEDES BENZ | E 350 3.5 4-Matic | (C207)[M276.957] | 02.2013- |
| MERCEDES BENZ | E 400 3.5 | (S212)[M276.820] | 01.2013- |
| MERCEDES BENZ | E 400 3.5 4-Matic | (S212)[M276.820] | 01.2013- |
| MERCEDES BENZ | ML 300 3.5 4-Matic | (W166)[M276.955] | 01.2014- |
| MERCEDES BENZ | ML 350 3.5 4-Matic | (W166)[M276.955] | 06.2011- |
| MERCEDES BENZ | S 350 3.5 CGi | (W221)[M276.950] | 04.2011-12.2013 |
| MERCEDES BENZ | SL 350 3.5 | (R231)[M276.954] | 02.2012- |
| MERCEDES BENZ | SL 400 3.5 | (R231)[M276.825] | 04.2014- |
| MERCEDES BENZ | SLK 350 3.5 | (R172)[M276.956] | 02.2011- |
Reference Information
0001147400 0001147401 0986023100 25-4241 254727 2769061200 2769062300 276906230080 3211 550.552.102 6519061200 88214629 91-15-7343 A2769061200 A2769062300 A276906230080 A6519061200 BOS0001147400 DRS0732 IM3162 LRS02569 LRS2569 STRE241 UD12704S UNIT BOM 120-6530View your shopping basket or Browse other items in Starter Motors.
