Specifications
| Length (L.1) | 168 mm |
| Mount Hole Center - Center (O.1) | 85 mm |
| Mount Hole Diameter (D.1) | 6 mm |
| Mount Hole Diameter (D.2) | 7 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Rotation | CW |
| Spigot Diameter (A) | 30 mm |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| YAMAHA | XVS 1300 A V-Star | 2010, 2011, 2012, 2013, 2014, 2015 | |
| YAMAHA | XVS 1300 BG V-Star Deluxe | 2015, 2016, 2017 | |
| YAMAHA | XVS 1300 C Stryker | 2011, 2012, 2013, 2014, 2015, 2016, 2017 | |
| YAMAHA | XVS 1300 C Stryker Bullet Cowl | 2015, 2016 | |
| YAMAHA | XVS 1300 CT V-Star Deluxe | 2013, 2014, 2015, 2016 | |
| YAMAHA | XVS 1300 CT V-Star Tourer | 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017 | |
| YAMAHA | XVS 950 C V-Star Tourer | 2016, 2017 | |
| YAMAHA | XVS 950 V-Star | 2016 |
Video/Publications
SMU0554
YAMAHA 5S7-81890-00-00
YAMAHA: 5S7-81890-00-00 5S7-81890-10-00 5S7818900000 5S7818901000
