Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 493.19 including GST
NZ$ 428.86 excluding GST
or four payments of $123.30
with
Learn More
each
A0820S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
9120144605Specifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 220 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.50 mm |
| OEM Product | No |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 16 mm |
| Pulley Outside Diameter (O.D.1) | 59.50 mm |
| Pulley Outside Diameter (O.D.2) | 92 mm |
| Pulley to Mount Distance (A) | 44 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | Trade 2.0 | [LD20] | 01.1985-12.1993 |
| NISSAN | Trade 2.0 | [LD20] | 01.1986-12.1993 |
| NISSAN | Trade 2.0 | [LD20] | 01.1993-12.1998 |
| NISSAN | Vanette 2.0 | [LD20] | 01.1986-12.1993 |
| NISSAN | Vanette 2.0 | [LD20] | 01.1987-12.1995 |
| NISSAN | Vanette E 2.0 | [LD20] | 01.1987-12.1995 |
Reference Information
| 0986037210 | BOSCH |
| 1516906R | DAF |
| 165.825.055.000 | PSH |
| 165.825.055.360 | PSH |
| 165.825.055.460 | PSH |
| 165.825.055.605 | PSH |
| 210276 | ERA |
| 22389R | WAI / TRANSPO |
| 23100-D9701 | NISSAN |
| 23100-D9703 | NISSAN |
| 23100-D9704 | NISSAN |
| 23100-D9706 | NISSAN |
| 23100D9711 | NISSAN |
| 23100D9712 | NISSAN |
| 23100D9713 | NISSAN |
| 28-1986 | ELSTOCK |
| 40757RIV | KUHNER |
| 437121 | VALEO |
| 8EL011711-781 | HELLA |
| 8EL730090-001 | HELLA |
| 9098 | CEVAM |
| 9120144605 | BOSCH |
| 9120144606 | BOSCH |
| 9120144627 | BOSCH |
| 9120334639 | BOSCH |
| 944390372100 | MAGNETI MARELLI |
| A130.928 | PSH |
| A147.492 | PSH |
| AEB0757 | AUTOELECTRO |
| AG0296 | GHIBAUDI |
| ALB0757 | KRAUF |
| ALT10151 | ELECTROLOG |
| ALT10439 | WOODAUTO |
| ALTL055 | 3EFFE |
| B310M-D9704EX | NISSAN |
| CGB-81986 | AINDE |
| DA4594 | DELCO |
| DRA3484 | DELCO |
| DRA3484N | DELCO |
| JA757IR | HC PARTS |
| LRA01457 | LUCAS |
| LRA1457 | LUCAS |
| MRA37210 | MAGNETI MARELLI |
| PRAL055 | 3EFFE |
| STX101206 | STARDAX |
| UD19402A | AS-PL |
