Brand new AS-PL Alternator
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 313.00 including GST
NZ$ 272.17 excluding GST
or four payments of $78.25
with
Learn More
each
A2126S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
- Information
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
LR155-20Specifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10 mm |
| Insulated Earth | Yes |
| Length (L.1) | 168.50 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.50 mm |
| OEM Product | No |
| Plug Code | PL_2500 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10 mm |
| Pulley Outside Diameter (O.D.1) | 48 mm |
| Pulley Outside Diameter (O.D.2) | 72 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | Solid |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| YANMAR | Engine | [2GM20] | 01.1984- |
| YANMAR | Engine | [2GM20-F] | 01.1984- |
| YANMAR | Engine | [3GM30] | 01.1984- |
| YANMAR | Engine | [3GM30-F] | |
| YANMAR | Engine | [3JH2-TE] | 01.1991-12.1999 |
| YANMAR | Engine | [3JH3-BE] | |
| YANMAR | Engine | [3JH3-E] | |
| YANMAR | Engine | [4JH2-DTBE] | |
| YANMAR | Engine | [4JH2-DTE] | |
| YANMAR | Engine | [4JH2-E] | |
| YANMAR | Engine | [4JH2-HTE] | |
| YANMAR | Engine | [4JH2M-E] | |
| YANMAR | Engine | [4JH2-TE] | |
| YANMAR | Engine | [4JH2-UTE] | |
| YANMAR | Engine | [4JH3-E] | |
| YANMAR | Engine | [4JH-4C] | 01.2005- |
| YANMAR | Engine | [4JH-DTBE] | |
| YANMAR | Engine | [4JH-DTE] | 01.1983-12.1989 |
| YANMAR | Engine | [4JH-DTXE] | |
| YANMAR | Engine | [4JH-E] | 01.1983-12.1989 |
| YANMAR | Engine | [4JH-HTE] | 01.1983-12.1989 |
| YANMAR | Engine | [4JH-HTXE] | |
| YANMAR | Engine | [4JH-TE] | 01.1989- |
| YANMAR | Engine | [4JH-TXE] | |
| YANMAR | Engine | [4JH-XE] | |
| YANMAR | Engine | [4LH-DTE] | 01.1989- |
| YANMAR | Engine | [4LH-HTE] | 01.1989- |
| YANMAR | Engine | [4LH-TE] | 01.1989- |
| YANMAR | Engine 1.5 | [4JM] | |
| YANMAR | Engine 1.5 | [4JM-T] |
Reference Information
| 113793 | CARGO |
| 12107N | WAI / TRANSPO |
| 129772-77200 | YANMAR |
| 20115006TBA | PRESTOLITE |
| 20145161BN | REAL |
| 20145161RC | REAL |
| 2020161.0 | SANDO |
| 2020161.2 | SANDO |
| 204-10121 | ROBERT'S |
| 28-0917 | ELSTOCK |
| 446035 | LOGISTIK |
| 5520943 | MEAT & DORIA |
| 553903RI | KUHNER |
| 75919 | EAI |
| 8EL737061-001 | HELLA |
| 90-25-1092 | WILSON |
| 90-25-1092N | WILSON |
| 985.003.055.080 | PSH |
| 985.003.055.265 | PSH |
| 985.003.055.780 | PSH |
| A12HT1123A2 | SIDAT |
| A-8519 | DIXIE |
| ALH3793 | KRAUF |
| ALT32040 | WOODAUTO |
| CAL20161AS | CASCO |
| CAL20161RS | CASCO |
| CGB-80917 | AINDE |
| F032113793 | CARGO |
| HAL15520B | HITACHI |
| JA986IR | HC PARTS |
| LR155-20 | HITACHI |
| LR155-20B | HITACHI |
| LR155-29 | HITACHI |
| LRA01248 | LUCAS |
| LRA1248 | LUCAS |
| UD19393A | AS-PL |
Video/Publications
A2126SRelated Items
