Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DELCO
Price:
NZ$ 547.17 including GST
NZ$ 475.80 excluding GST
or four payments of $136.79
with
Learn More
each
A1091S
No stock in NZ currently
No stock in NZ currently
Information
8600366Specifications
| Amp | 85 A |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 12.50 mm |
| Diameter (D.4) | 12.50 mm |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 70.50 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 80 mm |
| Pad mount thickness (E.2) | 80 mm |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 37 mm |
| Pulley Type | Solid |
| Unit Type | DELCO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | 312E 4.4 | [C4.4] | 01.2012-12.2016 |
| CATERPILLAR | 312E L 4.4 | [C4.4] | 01.2012-12.2018 |
| CATERPILLAR | 314E 4.4 | [C4.4] | 01.2013-12.2015 |
| CATERPILLAR | 314E CR 4.4 | [C4.4] | 01.2013-12.2015 |
| CATERPILLAR | 314E LCR 4.4 | [C4.4] | 01.2013-12.2016 |
| CATERPILLAR | 314E SR 4.4 | [C4.4] | 01.2013-12.2016 |
| CATERPILLAR | 316E L 4.4 | [C4.4] | 01.2012-12.2016 |
| CATERPILLAR | 318E L 4.4 | [C4.4] | 01.2012-12.2017 |
Reference Information
| 01JN16110309MA | CATERPILLAR |
| 06FE16134125MA | CATERPILLAR |
| 101-03205 | DIXIE |
| 20109136BN | REAL |
| 2060631.0 | SANDO |
| 21212N | WAI / TRANSPO |
| 240-13100 | ROBERT'S |
| 3218932 | CATERPILLAR |
| 555159RI | KUHNER |
| 646.511.085.030 | PSH |
| 8600366 | DELCO |
| A1091S | AS-PL |
| A134.672 | PSH |
| A-1818 | DIXIE |
| ALD8932 | KRAUF |
| ALT2327 | ELECTROLOG |
| ALT3000728 | WESTERN STAR |
| CAL60631AS | CASCO |
| CGB-18932 | AINDE |
| UD19455A | AS-PL |
Video/Publications
