Information
DAN1205Specifications
Amp | 150 A |
Diameter (D.1) | 10.50 mm |
Diameter (D.2) | 10.50 mm |
Diameter (D.3) | 12 mm |
Diameter (D.4) | 12 mm |
Length (L.1) | 164 mm |
Mount Inside Length or Pad Mount C-C (C) | 67 mm |
OEM Product | Yes |
Pad mount thickness (E.1) | 45 mm |
Pad mount thickness (E.2) | 98 mm |
Pad mount thickness (E.3) | 18 mm |
Pad mount thickness (E.4) | 92 mm |
Plug Code | PL_4000 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley Grooves | 8 qty |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley to Mount Distance (A) | 25 mm |
Pulley Type | Solid |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LEXUS | GX 460 4WD | [1UR-FE] | 01.2010- |
LEXUS | LX 570 | [3UR-FE] | 08.2007- |
LEXUS | LX 570 | [3UR-FE] | 11.2007- |
TOYOTA | Land Cruiser 4.6 V8 | [1UR-FE] | 01.2012- |
Reference Information
021080-1280 | DENSO |
104210-2830 | DENSO |
104210-2831 | DENSO |
104210-2832 | DENSO |
104211-8640 | DENSO |
104211-8641 | DENSO |
195.935.150.050 | PSH |
195.935.150.260 | PSH |
20132074OE | REAL |
2040470.1 | SANDO |
27060-38090 | TOYOTA |
27060-38110 | TOYOTA |
28-7798 | ELSTOCK |
40362 | CEVAM |
600000165550 | MAGNETI MARELLI |
ALN2830 | KRAUF |
ALT6720 | ELECTROLOG |
ALTE961 | 3EFFE |
CAL40470GS | CASCO |
DA2874 | DELCO |
DAN1205 | DENSO |
DENDAN1205 | WOODAUTO |
DRA1764 | DELCO |
J5112199 | HERTH+BUSS |
LRA04189 | LUCAS |
LRA4189 | LUCAS |
PRAE961 | 3EFFE |
UD805267(DENSO)A | AS-PL |
