Specifications
Kilowatt | 2.7 kW |
Length (L.1) | 295 mm |
Mount Hole Center - Center (O.1) | 147 mm |
Mount Hole Center - Center (O.2) | 104 mm |
Mount Hole Center - Center (O.3) | 104 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 25 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | 45.66 | [8035.06] | 01.1985-12.1989 |
FIAT | 465 2.6 | 01.1982-12.1984 | |
FIAT | 466 2.6 | 01.1982-12.1984 | |
FIAT | 480 2.6 | 01.1976-12.1982 | |
FIAT | 540S 2.6 | 01.1978-12.1982 | |
FIAT | 55.46 | [8035.06] | 01.1985-12.1988 |
FIAT | 55.65 | [55.65] | 01.1984-12.1989 |
FIAT | 55.66 | [8035.06] | 01.1984-12.1989 |
FIAT | 55.88 | [8035.06] | 01.1990-12.1991 |
FIAT | 55.9 | [8035.06] | 01.1984-12.1989 |
FIAT | 55.90 | [8035.06] | 01.1984-12.1989 |
FIAT | 565C 2.8 | 01.1982-12.1984 | |
FIAT | 566 2.8 | 01.1982-12.1984 | |
FIAT | 570 2.8 | 01.1977-12.1987 | |
FIAT | 580 2.8 | 01.1977-12.1984 | |
FIAT | 60.88 | [8035.05] | 01.1990-12.1992 |
FIAT | 60.9 | [8035.05] | 01.1984-12.1990 |
FIAT | 60.90 | [8035.05] | 01.1984-12.1990 |
Reference Information
91-15-6928 6030102.1 4682998 500338953 500333269 500.001.093.225 000986012670 LRS00850 6010373 986012670 STB0572 MSN227 IS0203 87376491 88212934 DRS2670 500.001.093.100 CST30102AS 26390 20401373BN STRL029 63217126 6030102 63217125 CST30102GS PRSL029 MAHMS388 82980757 110813 20500850 88205005 500.001.093.311 CST10373AS 0001362039 88205001 4710224 CS572 11.130.203 8615 4169096 0001362032 4722682 MT71AB MT71AA M125M3Z9 MT71A 10572M 10572B AZJ3538 72736016 5111319 4739353 1362039 17093N 84224935 0001362105 DS3780 1362032 UD49010S 26290 S0895S 4759929 LRS0850 20404201OE 4745929 63217101 20404201BN 220007 MS388 1362105 500.001.093.016 91-15-6928N 25-0465 4807373 33341 SG0126 CGB-22670 STR1285 4172113 500.001.093.010 LRS850 4728682Add Your Number
