Specifications
| Kilowatt | 4.8 kW |
| Length (L.1) | 320 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Center - Center (O.2) | 126 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| Mount Hole Diameter (C.3) | 13 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 47.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CUMMINS | C Series | 01.1997-12.2007 | |
| CUMMINS | Engines 8.3 | 01.1997-12.2007 |
Reference Information
228000-5901 228000-5902 228000-5900 6040321.1 STR70091 255981D STN4646 6040321 18508N 700.521.103.260 DRS0351 CST40321AS 190-30195 3283813 3283815 DS1461 STRL865 CST40321GS 3957590 91-29-5601 PRSL865 3920328 20432123BN DENDSN2024 228080-5902 DSN2024 3675288RX 700.521.103.050 255981 20432123OE 3675245RX 3675246RX UD19277SAdd Your Number
