Specifications
| Kilowatt | 0.7 kW |
| Length (L.1) | 205 mm |
| Mount Hole Center - Center (O.1) | 104 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 36 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAIHATSU | Cuore 1.0 | [1KR-FE] | 04.2007- |
| DAIHATSU | Sirion 1.0 | [1KR-FE] | 01.2005-06.2013 |
| SUBARU | Justy 1.0 | [1KR-FE] | 01.2007- |
Reference Information
LRS3912 28100-B1010 110.514.092.415 255458 UD18927S STR6222 6040595 428000-2550 25-5075 STN2490 DRS1123 LRS03912 CST40595ASAdd Your Number
