Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 351 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 128 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 32.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 312E | [C4.4] | 01.2012-12.2016 |
CATERPILLAR | 312EL | [C4.4] | 01.2012-12.2018 |
CATERPILLAR | 314E | [C4.4] | 01.2013-12.2015 |
CATERPILLAR | 314E CR | [C4.4] | 01.2013-12.2015 |
CATERPILLAR | 314E LCR | [C4.4] | 01.2013-12.2016 |
CATERPILLAR | 314E SR | [C4.4] | 01.2013-12.2016 |
CATERPILLAR | 316EL | [C4.4] | 01.2012-12.2016 |
CATERPILLAR | 318EL | [C4.4] | 01.2012-12.2017 |
CATERPILLAR | CP54B | [C4.4] | 01.2012-12.2019 |
CATERPILLAR | CP68B | [C4.4] | 01.2012-12.2019 |
CATERPILLAR | CP74B | [C4.4] | 01.2012-12.2019 |
CATERPILLAR | CS54B | [C4.4] | 01.2012-12.2012 |
CATERPILLAR | CS64B | [C4.4] | 01.2012-12.2012 |
CATERPILLAR | CS66B | [C4.4] | 01.2012-12.2012 |
CATERPILLAR | CS68B | [C4.4] | 01.2012-12.2012 |
CATERPILLAR | CS74B | [C4.4] | 01.2012-12.2012 |
CATERPILLAR | CS76B | [C4.4] | 01.2012-12.2012 |
CATERPILLAR | CS78B | [C4.4] | 01.2012-12.2012 |
Reference Information
255553M STR79288 701.517.103.310 STR60747 11.132.187 3218968 MAHMS147 UD811922(LETRIKA)S 6021618.1 AZF4839 STI4839 3826587 T411409 TS-6258 72735775 701.517.103.090 MS147 AZF4699 11.131.899 CST21618GS 182-30458 IS1294 20419816OEAdd Your Number
