Associated Numbers
410502082 PSH
462370895001 Piaggio
462Q370895001 Piaggio
471QLR3708950 Piaggio
471QLR3708950PW Piaggio
410502082 PSH
462370895001 Piaggio
462Q370895001 Piaggio
471QLR3708950 Piaggio
471QLR3708950PW Piaggio
AIS224 ATK
ALT46001 Wood Auto
B011155 Piaggio
QD1121B Piaggio
QD1168 Piaggio
QD1226J Piaggio
QDJ1226J Piaggio
WOOALT46001 Wood Auto
AIS224 AES
ALT46001 Wood Auto
B011155 Piaggio
QD1121B Piaggio
QD1168 Piaggio
QD1226J Piaggio
QDJ1226J Piaggio
WOOALT46001 Wood Auto
CST38104 CASCO
255049 Kühner
462Q370895001 Piaggio
471QLR3708950 Piaggio
471QLR3708950PW Piaggio
B011155 Piaggio
410,502,082 Psh
QD1168 QD (CHINA)
QD1226J QD (CHINA)
QDJ1226J QD (CHINA)
6038104.1 Sando
Specifications
Kilowatt | 0.8 kW |
Length (L.1) | 237 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 25.5 mm |
Rotation | ACW |
Spigot Diameter (A) | 65 mm |
Unit Type | OTHER |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
PIAGGIO | Various Models |
Reference Information
339171 4.62371E+11 6038104.1 20415401OE B011155 410502082 254931M 410.502.082.200 CST38104GS QD1121B QD1226J 462Q370895001 UD19583SAdd Your Number
