Specifications
Inside Diameter (I.D.1) | 12 mm |
Length (L.1) | 137 mm |
Length (L.2) | 68.5 mm |
No./Splines | 10 qty |
No./Teeth | 10 qty |
Outside Diameter (O.D.1) | 60.2 mm |
Outside Diameter (O.D.2) | 39.6 mm |
Rotation | CW |
Type | Drive |
Unit Type | ISKRA / LETRIKA |
Reference Information
16.902.035 16.913.005 16.902.036 MSX164 333910 69-52-10 MAHMSX164 060.000.906.830 SDI2036 1994 01-014 DRV79016 81019244 GEAR7906 UD19824SDVideo/Publications
11131839 11132547 11132206 11132416 AZF4627 11131830 AZF4869 11131501 11131798 11131411 11132104 AZF4646 AZF4889 AZF4687 AZF4831 AZF4842 11131260 AZF4683 AZF4691Add Your Number
