Information
FG12S011Specifications
Amp | 130 A |
Diameter (D.1) | 8 mm |
Diameter (D.2) | 8 mm |
Diameter (D.3) | 10 mm |
Length (L.1) | 158 mm |
Mount Inside Length or Pad Mount C-C (C) | 55 mm |
OEM Product | No |
Pad mount thickness (E.1) | 79 mm |
Pad mount thickness (E.2) | 79 mm |
Plug Code | PL_2201 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 5 qty |
Pulley Outside Diameter (O.D.1) | 56.50 mm |
Pulley to Mount Distance (A) | 31.50 mm |
Pulley Type | Solid |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | HHR 2.4 | [LE5] | 01.2006-12.2011 |
Reference Information
11266N | WAI / TRANSPO |
11266R | WAI / TRANSPO |
12588321 | GM |
13500316 | GM |
13588321 | GM |
15828450 | GM |
15923218 | GM |
2015A48.1 | SANDO |
2017984AOE | REAL |
20758749 | GM |
22762984 | GM |
2613695 | VALEO |
2613695A | VALEO |
2650532 | VALEO |
420532 | VALEO |
554517RI | KUHNER |
849105 | VALEO |
89216352 | POWERMAX |
90-22-5596 | WILSON |
90-22-5596N | WILSON |
ALV8321 | KRAUF |
CAL15A48GS | CASCO |
FG12S010 | VALEO |
FG12S011 | VALEO |
FG12S014 | VALEO |
FG12S045 | VALEO |
FG12S081 | VALEO |
FGNS104 | VALEO |
UD19453A | AS-PL |
Video/Publications
