Specifications
| Amp | 75 A |
| Bottom Mounting Foot Width (B) | 58 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Grooves | 4 qty |
| Length (L.1) | 156 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 54 mm |
| Plug Code | PL_3302 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley to Mount Distance (A) | 90 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Swift 1.3 | [M13A] | 01.2005-12.2010 |
| SUZUKI | Swift 1.3 | [M13A] | 02.2005- |
| SUZUKI | Swift 1.5 | [M15A] | 01.2005-12.2010 |
| SUZUKI | Swift 1.5 | [M15A] | 02.2005- |
| SUZUKI | Wagon 1.3 | [M13A] | 01.2003-12.2008 |
| SUZUKI | Wagon R+ 1.3 | [M13A] | 09.2003- |
| SUZUKI | Wagon R+ 1.3 VVT 4WD | [M13A] | 09.2003- |
Reference Information
113812 4G0534 J5118016 722424/M 20137452OE LRA02954 A005TB1291AM A005TB1291ZE SKGN-0320756 209367 802-16097 2035254.1 9.44391E+11 4-0107 AC-CBA1943 A005TB0891 4G0254 28-5568 20137452BN 3113618 011-003-000948R 129ST75 STX100520R A5TB1291 89212880 986081950 3140062J00 MITA5TB1291 9051816 WG2281049 9391 CAL35254AS AL02615 23927R QRA2343 AZMT-49-035-1756 06-10501-SX 314008400 TT12654 0986081950 ANM32374X A005TB1291AE 12060948 ALTS949 WOOALT31311 A5TB0891 IR6840 23954N SKGN-0320254 A005TB0891ZE ALT31311 ALM1943 PRAS949 CA1943IR 57129 LRA2954 3140084E01000 L84770 EAL-8505 SZ8006 A005TB1291 RAA11265 301943RIM 8EL738212-831 301943RI AMI254A AMI254 A5TB1291AM A5TB1291ZE F042200112 185.535.075.370 185.535.075.130 F042A0H208 BBA3014 MQA1943 4851816 0F042A0H208 A5TB0891ZE DRA0154 185.535.075.138 245125752 5535885 10443767 31400-84E00 3140084E02000 31400-84E01 31400-84E02 0F042200112 2035254 63731943010 STX100520 114245 CAL35254GSAdd Your Number
