Specifications
Amp | 125 A |
Bottom Mounting Foot Width (B) | 16 mm |
Diameter (D.1) | M10x1.25 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Grooves | 6 qty |
Length (L.1) | 167 mm |
Mount Inside Length or Pad Mount C-C (C) | 65 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 25 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | RAV4 2.5 4x4 Hybrid E-CVT | [2AR-FE] | 01.2013-12.2018 |
TOYOTA | RAV4 2.5 Hybrid E-CVT | [2AR-FE] | 01.2013-12.2018 |
Reference Information
14486R 104211-3541 27060-0V170 UD19681A 14486NAdd Your Number
