Specifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 19 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Grooves | 5 qty |
Length (L.1) | 152 mm |
Mount Inside Length or Pad Mount C-C (C) | 36.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 52.5 mm |
Plug Code | PL_4002 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 29 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SUBARU | Trezia 1.3 | [1NR-FE] | 03.2011- |
SUBARU | Trezia 1.3 | [1NR-FKE] | 03.2011- |
TOYOTA | Verso S 1.3 | [1NR-FE] | 11.2010-10.2016 |
TOYOTA | Yaris 1.3 | [1NR-FE] | 09.2011- |
TOYOTA | Yaris 1.3 | [1NR-FKE] | 09.2011- |
Reference Information
27060-47130 UD21173A J5112194Add Your Number
