Information
DAN1096Associated Numbers
1012101750 Denso
195999090 PSH
270600T190 Toyota
287547 Denso
931446 EDR
DAN1096 Denso
DRA1446 Remy
LRA03937 Lucas
Specifications
Amp | 90 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Length (L.1) | 175 mm |
Mount Inside Length or Pad Mount C-C (C) | 51 mm |
OEM Product | Yes |
Plug Code | PL_1100 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley Grooves | 6 qty |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley to Mount Distance (A) | 34 mm |
Pulley Type | Clutch |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Auris 1.6 | [1ZR-FAE] | 10.2012-12.2018 |
TOYOTA | Auris 1.6 Touring Sports | [1ZR-FAE] | 07.2013-12.2018 |
TOYOTA | Corolla 1.6 | [1ZR-FAE] | 06.2013-12.2018 |
Reference Information
063377577010 | MAGNETI MARELLI |
101210-1750 | DENSO |
195.999.090.260 | PSH |
20132424OE | REAL |
2040424.1 | SANDO |
210967 | ERA |
27060-0T190 | TOYOTA |
28-7547 | ELSTOCK |
40016 | CEVAM |
554453RID | KUHNER |
89216026 | POWERMAX |
AEK3937 | AUTOELECTRO |
ALN9610 | KRAUF |
ALT6462 | ELECTROLOG |
ALTE782 | 3EFFE |
CAL40424GS | CASCO |
DAN1096 | DENSO |
DENDAN1096 | WOODAUTO |
DRA1446 | DELCO |
J5112209 | HERTH+BUSS |
LRA03937 | LUCAS |
LRA3937 | LUCAS |
MAN7577 | MAGNETI MARELLI |
PRAE782 | 3EFFE |
UD810064(DENSO)A | AS-PL |
Video/Publications
