Specifications
Kilowatt | 1.1 kW |
Length (L.1) | 210 mm |
Mount Hole Center - Center (O.1) | 150.5 mm |
Mount Hole Diameter (C.1) | 12.5 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 52 mm |
Rotation | ACW |
Spigot Diameter (A) | 76 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
AUDI | A2 1.4 | [AUA] | 02.2000-08.2005 |
AUDI | A2 1.4 | [BBY] | 02.2000-08.2005 |
AUDI | A2 1.6 FSi | [BAD] | 05.2002-08.2005 |
SEAT | Ibiza 1.2 | [AZQ] | 02.2002-06.2006 |
SEAT | Ibiza 1.2 | [BME] | 02.2002-06.2006 |
SEAT | Ibiza 1.4 16V | [AUB] | 02.2002-11.2009 |
SEAT | Ibiza 1.4 16V | [BBY] | 02.2002-12.2007 |
SEAT | Ibiza 1.4 16V | [BBZ] | 02.2002-11.2009 |
SEAT | Ibiza 1.4 16V | [BKY] | 02.2002-12.2007 |
SKODA | Fabia 1.4 16V | [AUA] | 05.2000-12.2007 |
SKODA | Fabia 1.4 16V | [AUA] | 10.1999-12.2007 |
SKODA | Fabia 1.4 16V | [AUA] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [AUB] | 04.2000-12.2007 |
SKODA | Fabia 1.4 16V | [AUB] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [AUB] | 12.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BBY] | 05.2000-12.2007 |
SKODA | Fabia 1.4 16V | [BBY] | 10.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BBY] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [BBZ] | 04.2000-12.2007 |
SKODA | Fabia 1.4 16V | [BBZ] | 12.1999-03.2008 |
SKODA | Fabia 1.4 16V | [BBZ] | 12.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BKY] | 05.2000-12.2007 |
SKODA | Fabia 1.4 16V | [BKY] | 10.1999-12.2007 |
SKODA | Fabia 1.4 16V | [BKY] | 12.1999-03.2008 |
VW | Bora 1.6 FSi | [BAD] | 01.2002-05.2005 |
VW | Golf IV 1.6 FSi | [BAD] | 01.2002-06.2005 |
VW | Golf IV 1.6 FSi | [BAD] | 01.2002-06.2006 |
VW | Lupo 1.6 GTi | [AVY] | 09.2000-07.2005 |
VW | New Beetle 1.4 | [BCA] | 11.2001-09.2010 |
VW | Polo 1.2 | [AWY] | 01.2002-05.2007 |
VW | Polo 1.2 | [BMD] | 01.2002-05.2007 |
VW | Polo 1.2 12V | [AZQ] | 10.2001-07.2007 |
VW | Polo 1.2 12V | [BME] | 10.2001-07.2007 |
VW | Polo 1.4 16V | [AUA] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [AUB] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [BBY] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [BBZ] | 10.2001-05.2008 |
VW | Polo 1.4 16V | [BKY] | 10.2001-05.2008 |
Reference Information
63721197010 02T911023GX 2T911023D 2T911023E 101197 2T911023G LRT00220 8EA012527-401 CST15129GS 1120400 1121016 31220R 02T911023G 02T911023E 02T911023D 2T911023EX M1203H 02T911023A 6010139 DRS8430 AI-80003 STM1037 112435 6015129.1 20479921OE CST10139AS 9.4428E+11 11911 42018430 02T91102G F000CD0100 S12BH0176A2 0001120400 0001121016 000F000CD0100 02T911023EX 101197B 6010139.1 2T911023GX CS1197 3016 986018430 101197V 000986018430 5010026 20401931BN F000CD0801 F000CD0800 31220N STR1327 CST10139GS AES2220 201035 25-2485 S12BH0176 EAA-121129 LRT220 300.537.102.010 20401931OE 300.537.102.210 STR50183 000F000CD0800 000F000CD0801 20513018 88212348Add Your Number
