Remanufactured AS-PL Starter motor
PREMIUM LINE
AS-PL
HITACHI
Price:
NZ$ 302.00 including GST
NZ$ 262.61 excluding GST
or four payments of $75.50
with
Learn More
each
S2116PR
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Kilowatt | 1.20 kW |
| Length (L.1) | 202 mm |
| Mount Hole Center - Center (O.1) | 106 mm |
| Mount Hole Center - Center (O.2) | 30 mm |
| Mount Hole Center - Center (O.3) | 130 mm |
| Mount Hole Diameter (C.1) | M12x1.75 mm |
| Mount Hole Diameter (C.2) | 10.50 mm |
| Mount Hole Diameter (C.3) | 13 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 17.50 mm |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Rotation | CW |
| Spigot Diameter (A) | 78 mm |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ISUZU | Gemini 1.5 TD | [4EC1T] | 02.1988-12.1989 |
| ISUZU | Gemini 1.5 TD | [4EC1T] | 02.1988-12.1990 |
| OPEL | Astra 1.7 TD | [17TD] | 03.1995-02.1998 |
| OPEL | Astra 1.7 TDS | [17DT] | 12.1991-01.1998 |
| OPEL | Astra 1.7 TDS | [17TD] | 03.1992-09.1998 |
| OPEL | Astra 1.7 TDS | [X17TD] | 12.1991-01.1998 |
| OPEL | Corsa 1.5 TD | [15DT(T4EC1)] | 03.1988-03.1993 |
| OPEL | Corsa 1.5 TD | [15DT(T4EC1)] | 10.1987-03.1993 |
| OPEL | Kadett 1.5 TD | [15TD] | 07.1988-08.1991 |
| OPEL | Vectra 1.7 TD | [17DT] | 03.1990-11.1995 |
| OPEL | Vectra 1.7 TD | [17TD] | 03.1990-11.1995 |
| OPEL | Vectra 1.7 TD | [X17TD] | 03.1990-11.1995 |
Reference Information
| 003-U950 | ASHIKA |
| 09163854 | OPEL |
| 09512049 | OPEL |
| 0986016161 | BOSCH |
| 11685 | EAI |
| 1202015 | OPEL |
| 1202149 | OPEL |
| 1202167 | OPEL |
| 130.513.092.265 | PSH |
| 130.513.092.415 | PSH |
| 18327R | WAI / TRANSPO |
| 20445121BN | REAL |
| 20753 | KUHNER |
| 25-1425 | ELSTOCK |
| 335603 | LOGISTIK |
| 3U950 | JAPKO |
| 455744 | VALEO |
| 6020121.0 | SANDO |
| 88212203 | POWERMAX |
| 894332-5860 | ISUZU |
| 897117-7690 | ISUZU |
| 8971777690 | ISUZU |
| 8-97177-769-0 | ISUZU |
| 8EA011610-881 | HELLA |
| 8EA731788-001 | HELLA |
| 90542411 | OPEL |
| 943251352010 | MAGNETI MARELLI |
| 943254002010 | MAGNETI MARELLI |
| 94332586 | OPEL |
| 944280800100 | MAGNETI MARELLI |
| 97117769 | OPEL |
| 9740 | CEVAM |
| AES8149 | AUTOELECTRO |
| CGB-23002 | AINDE |
| CGB-51425 | AINDE |
| CST20121AS | CASCO |
| DRS3216 | DELCO |
| JS753 | HC PARTS |
| LRS00849 | LUCAS |
| LRS0849 | LUCAS |
| LRS849 | LUCAS |
| MAV5060A | SIOM |
| MRS80010 | MAGNETI MARELLI |
| MSR2002 | MAGNETI MARELLI |
| MTU950 | JAPANPARTS |
| PRSS137 | 3EFFE |
| R1040023 | OPEL |
| S114-481 | HITACHI |
| S114-481A | HITACHI |
| STH0753 | KRAUF |
| STR3260 | ELECTROLOG |
| STR72103 | WOODAUTO |
| STRS137 | 3EFFE |
| STX200154 | STARDAX |
Video/Publications
