Remanufactured AS-PL Starter motor
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 369.09 including GST
NZ$ 320.95 excluding GST
or four payments of $92.27
with
Learn More
each
S4017SR
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Kilowatt | 2.60 kW |
| Length (L.1) | 272 mm |
| Mount Hole Center - Center (O.1) | 116 mm |
| Mount Hole Center - Center (O.2) | 82 mm |
| Mount Hole Center - Center (O.3) | 82 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 24 mm |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Rotation | CW |
| Spigot Diameter (A) | 81.50 mm |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | Jumper 2.8 HDi | [8140.43S] | 04.2002- |
| CITROEN | Jumper 2.8 HDi | [8140.43S] | 09.2000-04.2002 |
| CITROEN | Jumper 2.8 HDi 4x4 | [8140.43S] | 09.2000-04.2002 |
| FIAT | Ducato 1.9 D | [230A2.000] | 03.1994-04.2002 |
| FIAT | Ducato 2.8 D | [8140.63] | 02.1998-04.2002 |
| FIAT | Ducato 2.8 D | [8140.63] | 05.1998-04.2002 |
| FIAT | Ducato 2.8 D 4x4 | [8140.63] | 08.1998-04.2002 |
| FIAT | Ducato 2.8 TDi | [8140.43] | 10.1997-04.2002 |
| FIAT | Ducato 2.8 TDi 4x4 | [8140.43] | 06.1999-04.2002 |
| FIAT | Ducato 2.8 TDi 4x4 | [8140.43] | 07.1999-04.2002 |
| PEUGEOT | Boxer 2.8 HDi | [8140.43S(F28DTCR)] | 11.2000-04.2002 |
| PEUGEOT | Boxer 2.8 HDi 4x4 | [8140.43S(F28DTCR)] | 10.2000-04.2002 |
Reference Information
| 063114014010 | MAGNETI MARELLI |
| 0986018960 | BOSCH |
| 0986021041 | BOSCH |
| 101109 | KUHNER |
| 101109B | KUHNER |
| 101109D | KUHNER |
| 10973 | KUHNER |
| 112026 | CARGO |
| 11854 | EAI |
| 131955508 | FIAT |
| 1319555080 | PEUGEOT |
| 1329201080 | IVECO |
| 1329201080 | FIAT |
| 1331329080 | PEUGEOT |
| 1349920080 | FIAT |
| 1608944780 | PEUGEOT |
| 20401261BN | REAL |
| 20401261OE | REAL |
| 20404901BN | REAL |
| 20404901IT | REAL |
| 20404901OE | REAL |
| 20510188 | PRESTOLITE |
| 220158 | ERA |
| 220165 | ERA |
| 22.1109 | LAUBER |
| 22.1109M | LAUBER |
| 25-2232 | ELSTOCK |
| 33224N | WAI / TRANSPO |
| 3326 | CEVAM |
| 3671 | CEVAM |
| 42018960 | HERTH+BUSS |
| 46208436 | PEUGEOT |
| 46231646 | FIAT |
| 46758240 | FIAT |
| 500.524.093.050 | PSH |
| 500.524.093.311 | PSH |
| 5802EC | PEUGEOT |
| 5802EE | PEUGEOT |
| 5802Y9 | PEUGEOT |
| 5802Z0 | PEUGEOT |
| 5802Z1 | PEUGEOT |
| 5802Z3 | PEUGEOT |
| 580SZ1 | PEUGEOT |
| 6010162.0 | SANDO |
| 6010162.1 | SANDO |
| 6030109.0 | SANDO |
| 6030109.1 | SANDO |
| 6030109.5 | SANDO |
| 63114014 | MAGNETI MARELLI |
| 71721242 | PEUGEOT |
| 71721243 | PEUGEOT |
| 71723353 | FIAT |
| 71782324 | PEUGEOT |
| 71782325 | PEUGEOT |
| 71786770 | FIAT |
| 71786771 | FIAT |
| 8029647 | IVECO |
| 80296470 | FIAT |
| 8080022 | FRIESEN |
| 88212136 | POWERMAX |
| 8EA011610-931 | HELLA |
| 8EA737526-001 | HELLA |
| 943114014010 | MAGNETI MARELLI |
| 943221281010 | MAGNETI MARELLI |
| 944280800220 | MAGNETI MARELLI |
| 9625382480 | PEUGEOT |
| AES1288 | AUTOELECTRO |
| CS1109 | HC PARTS |
| CST10162AS | CASCO |
| CST10162GS | CASCO |
| CST30109AS | CASCO |
| CST30109GS | CASCO |
| CST30109IS | CASCO |
| DRS3557 | DELCO |
| DS4667 | DELCO |
| DSN502 | DENSO |
| DSN582 | DENSO |
| F032112026 | CARGO |
| GS114014-A | GPARTS |
| K1319555080 | FIAT |
| K1329201080 | FIAT |
| K1331329080 | FIAT |
| LRT00188 | LUCAS |
| LRT188 | LUCAS |
| MAV2030 | SIOM |
| MAV2030A | SIOM |
| MAV6730 | SIOM |
| MRS80022 | MAGNETI MARELLI |
| MSN801 | MAGNETI MARELLI |
| PRSL128 | 3EFFE |
| RAS34668 | DELCO |
| RNL63114014 | RNL |
| S12MA0146A2 | SIDAT |
| STE1109 | KRAUF |
| STR52002 | WOODAUTO |
| STR90010 | ELECTROLOG |
| STRL128 | 3EFFE |
| STX200042 | STARDAX |
| STX200042R | STARDAX |
| STX200067 | STARDAX |
| STX200091 | STARDAX |
| STX200091R | STARDAX |
