Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 201 mm |
| Mount Hole Center - Center (O.1) | 123 mm |
| Mount Hole Diameter (C.1) | M12x1.25 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 25 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | RAV4 2.0 D4-D | [1AD-FTV] | 01.2012- |
| TOYOTA | RAV4 2.0 D4-D 4WD | [1AD-FTV] | 01.2012- |
| TOYOTA | RAV4 2.2 D4-D 4WD | [2AD-FHV] | 01.2012- |
| TOYOTA | RAV4 2.2 D4-D 4WD | [2AD-FTV] | 01.2012- |
Reference Information
428080-9482 6040401.1 CGB-55078 DSN1235 DRS0953 6040401 255439D PRSE516 9638 190.920.092.260 28100-26181 STRE516 S6240S 88215227 28100-26180 STN6180 LRS3915 428000-9482 STR70539 CST40401GS 220940 CST40401AS 428000-9481 DENDSN1235 20432104BN 428000-9480 STR6692 20432104OE 12409 AEX1244 UD19724S 190.920.092.050 LRS03915 25-5078Add Your Number
