Specifications
Kilowatt | 2 kW |
Length (L.1) | 230 mm |
Mount Hole Center - Center (O.1) | 121 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 13 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Auris 1.4 D-4D | [1ND-TV] | 03.2007-09.2012 |
TOYOTA | Corolla 1.4 D-4D | [1ND-TV] | 10.2006-07.2014 |
TOYOTA | Urban Cruiser 1.4 D-4D | [1ND-TV] | 01.2009-04.2014 |
TOYOTA | Urban Cruiser 1.4 D-4D 4WD | [1ND-TV] | 01.2009-04.2014 |
TOYOTA | Verso S 1.4 D4-D | [1ND-TV] | 11.2010-10.2016 |
TOYOTA | Yaris 1.4 D | [1ND-TV] | 09.2011- |
TOYOTA | Yaris 1.4 D-4D | [1ND-TV] | 08.2005-12.2012 |
Reference Information
9744 28100-33120 88214089 28100-33121 PRSF475 DRS0657 LRS02511 STN4424 6040319.1 DRS0699 428000-6200 254608 5040616 190.902.102.260 428000-6070 428000-6071 CST40319GS S12DE0590A2 STM1320 STRF475 28100-0N050 LRS2511 DSN946 190.902.102.050 DS1767 31239N 28100-33100 254608D 31239R J5212139 EAA-141329 63280073010 8EA012140-511 CS1549 CGB-23252 220928 20432913OE 115644 AEY2511 STR6414 428000-6090 DENDSN946 336049 J5212148 STR70459 25-4183 SG1137 MSN8073 12269 AEX1109Add Your Number
