Specifications
Kilowatt | 1.1 kW |
Length (L.1) | 201 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 27 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MERCEDES BENZ | C 160 1.8 Kompressor | (CL203)[M271.921] | 05.2002-05.2008 |
MERCEDES BENZ | C 180 1.8 | (C204)[M271.820] | 06.2011- |
MERCEDES BENZ | C 180 1.8 CGi | (W204)[M271.820] | 01.2007-01.2014 |
MERCEDES BENZ | C 180 1.8 CGi T-Model | (S204)[M271.820] | 11.2009-08.2014 |
MERCEDES BENZ | C 180 1.8 Kompressor | (CL203)[M271.946] | 05.2002-05.2008 |
MERCEDES BENZ | C 180 1.8 Kompressor | (W203)[M271.946] | 05.2002-02.2007 |
MERCEDES BENZ | C 180 1.8 Kompressor | (W204)[M271.910] | 01.2008-01.2014 |
MERCEDES BENZ | C 180 1.8 Kompressor | (W204)[M271.952] | 01.2007-01.2014 |
MERCEDES BENZ | C 180 1.8 Kompressor T-Mode | (S203)[M271.946] | 05.2002-08.2007 |
MERCEDES BENZ | C 180 1.8 Kompressor T-Model | (S204)[M271.910] | 01.2008-08.2014 |
MERCEDES BENZ | C 180 1.8 Kompressor T-Model | (S204)[M271.952] | 08.2007-08.2014 |
MERCEDES BENZ | C 200 1.8 CGi | (C204)[M271.860] | 06.2011- |
MERCEDES BENZ | C 200 1.8 CGi | (W204)[M271.820] | 01.2007-01.2014 |
MERCEDES BENZ | C 200 1.8 CGi | (W204)[M271.860] | 01.2007-01.2014 |
MERCEDES BENZ | C 200 1.8 CGi Kompressor | (CL203)[M271.942] | 03.2003-05.2008 |
MERCEDES BENZ | C 200 1.8 CGi Kompressor | (W203)[M271.942] | 07.2003-02.2007 |
MERCEDES BENZ | C 200 1.8 CGi Kompressor T-Model | (S203)[M271.942] | 07.2003-08.2007 |
MERCEDES BENZ | C 200 1.8 CGi T-Model | (S204)[M271.820] | 08.2007-08.2014 |
MERCEDES BENZ | C 200 1.8 CGi T-Model | (S204)[M271.860] | 08.2007-08.2014 |
MERCEDES BENZ | C 200 1.8 Kompressor | (CL203)[M271.940] | 05.2002-05.2008 |
MERCEDES BENZ | C 200 1.8 Kompressor | (W203)[M271.940] | 05.2002-02.2007 |
MERCEDES BENZ | C 200 1.8 Kompressor | (W204)[M271.950] | 01.2007-01.2014 |
MERCEDES BENZ | C 200 1.8 Kompressor T-Model | (S203)[M271.940] | 05.2002-08.2007 |
MERCEDES BENZ | C 200 1.8 Kompressor T-Model | (S204)[M271.950] | 08.2007-08.2014 |
MERCEDES BENZ | C 220 1.8 | (CL203)[M271.940] | 05.2002-05.2008 |
MERCEDES BENZ | C 230 1.8 Kompressor | (CL203)[M271.948] | 05.2002-05.2008 |
MERCEDES BENZ | C 230 1.8 Kompressor | (W203)[M271.948] | 02.2004-02.2007 |
MERCEDES BENZ | C 230 1.8 Kompressor T-Model | (S203)[M271.948] | 02.2004-08.2007 |
MERCEDES BENZ | C 250 1.8 | (C204)[M271.860] | 06.2011- |
MERCEDES BENZ | C 250 1.8 CGi | (W204)[M271.860] | 07.2009-01.2014 |
MERCEDES BENZ | C 250 1.8 CGi T-Model | (S204)[M271.860] | 07.2009-08.2014 |
MERCEDES BENZ | CLC 160 1.8 | (CL203)[M271.911] | 02.2009-06.2011 |
MERCEDES BENZ | CLC 180 1.8 Kompressor | (CL203)[M271.946] | 05.2008-06.2011 |
MERCEDES BENZ | CLC 200 1.8 Kompressor | (CL203)[M271.957] | 05.2008-06.2011 |
MERCEDES BENZ | CLK 200 1.8 CGi | (C209)[M271.942] | 07.2003-05.2009 |
MERCEDES BENZ | CLK 200 1.8 Kompressor | (A209)[M271.940] | 02.2003-03.2010 |
MERCEDES BENZ | CLK 200 1.8 Kompressor | (A209)[M271.955] | 10.2006-03.2010 |
MERCEDES BENZ | CLK 200 1.8 Kompressor | (C209)[M271.940] | 09.2002-05.2009 |
MERCEDES BENZ | CLK 200 1.8 Kompressor | (C209)[M271.955] | 10.2006-05.2009 |
MERCEDES BENZ | E 200 1.8 CGi | (A207)[M271.820] | 01.2010-12.2016 |
MERCEDES BENZ | E 200 1.8 CGi | (A207)[M271.860] | 01.2010-12.2016 |
MERCEDES BENZ | E 200 1.8 CGi | (C207)[M271.820] | 01.2010-12.2016 |
MERCEDES BENZ | E 200 1.8 CGi | (C207)[M271.860] | 01.2010-12.2016 |
MERCEDES BENZ | E 200 1.8 CGi | (W212)[M271.820] | 08.2009-12.2015 |
MERCEDES BENZ | E 200 1.8 CGi | (W212)[M271.860] | 08.2009-12.2015 |
MERCEDES BENZ | E 200 1.8 CGi T-Model | (S212)[M271.860] | 11.2009-12.2016 |
MERCEDES BENZ | E 200 1.8 Kompressor | (W211)[M271.941] | 11.2002-12.2008 |
MERCEDES BENZ | E 200 1.8 Kompressor | (W211)[M271.956] | 04.2006-12.2008 |
MERCEDES BENZ | E 200 1.8 Kompressor T-Model | (S211)[M271.956] | 04.2006-07.2009 |
MERCEDES BENZ | E 200 1.8 NGT | (W211)[M271.941] | 03.2004-12.2008 |
MERCEDES BENZ | E 200 1.8 NGT | (W212)[M271.958] | 03.2011-12.2015 |
MERCEDES BENZ | E 200 1.8 T Kompressor T-Model | (S211)[M271.941] | 03.2003-07.2009 |
MERCEDES BENZ | E 250 1.8 CGi | (A207)[M271.860] | 01.2010-12.2016 |
MERCEDES BENZ | E 250 1.8 CGi | (C207)[M271.860] | 01.2009-12.2016 |
MERCEDES BENZ | E 250 1.8 CGi | (W212)[M271.860] | 01.2009-12.2015 |
MERCEDES BENZ | E 250 1.8 CGi T-Model | (S212)[M271.860] | 11.2009-12.2013 |
MERCEDES BENZ | SLK 200 1.8 | (R172)[M271.860] | 02.2011- |
MERCEDES BENZ | SLK 200 1.8 | (R172)[M271.861] | 02.2011- |
MERCEDES BENZ | SLK 200 1.8 Kompressor | (R171)[M271.944] | 03.2004-02.2011 |
MERCEDES BENZ | SLK 200 1.8 Kompressor | (R171)[M271.954] | 01.2008-02.2011 |
MERCEDES BENZ | SLK 250 1.8 | (R172)[M271.860] | 02.2011- |
MERCEDES BENZ | SLK 250 1.8 | (R172)[M271.861] | 02.2011- |
MERCEDES BENZ | Sprinter 1.8 216 | (B906)[M271.951] | 09.2008- |
MERCEDES BENZ | Sprinter 1.8 216 | (B906)[M271.951] | 09.2008-05.2016 |
MERCEDES BENZ | Sprinter 1.8 316 | (B906)[M271.951] | 09.2008- |
MERCEDES BENZ | Sprinter 1.8 316 LGT | (B906)[M271.951] | 09.2008- |
MERCEDES BENZ | Sprinter 1.8 316 NGT | (B906)[M271.951] | 09.2008- |
MERCEDES BENZ | Sprinter 1.8 516 | (B906)[M271.951] | 03.2009- |
MERCEDES BENZ | Sprinter 1.8 516 | (B906)[M271.951] | 09.2008- |
MERCEDES BENZ | Sprinter 1.8 516 NGT | (B906)[M271.951] | 09.2008- |
Reference Information
STRW132 S12BH0148A2 6010247.1 0001107540 1107540 A0051513901C 550.524.092.260 5151400180 CST10247AS AI-80002 LRS01701 A0051514001 CST10247GS 17920N 101283 000986020350 42020350 000986020357 A005151390180 220667 726203 9.4428E+11 DRT0350 A0071510001 550.524.092.210 201054 438493 CS1283 550.524.092.010 PRSW132 3203 A0051513901 88212841 260540-5020 550.524.092.215 0001107406 458641 550.524.092.211 113513 A005151400180 8EA012527-981 986020357 S12BH0148 428000-1650 550.524.092.280 986020350 A0071510001C LRS1701 MAV122470A 8EA738110-001 71510001 STR50277 51514001 1107406 UD815158(DENSO)S STM1029 101283B 20401742OE STB1283 5151390180 DT1460 DENDSN3010 51513901 AEU1283 DSN3010 20401742BN 6010247 25-3251Add Your Number
