Specifications
B+ Stud Diameter & Thread Pitch (B+) | UNC 1/2-13 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | UNC 1/2-13 mm |
Coil Bolt Length | 14.5 mm |
Inside Diameter (I.D.1) | 32.8 mm |
L.B+ | 25.6 mm |
Length (L.1) | 121.5 mm |
Outside Diameter (O.D.1) | 68.3 mm |
Outside Diameter (O.D.2) | 76.5 mm |
Unit Type | DELCO |
Voltage | 24 V |
Reference Information
SOL2726 CSO60602GS E5385 AME0034 SNLS-D43 054.000.255.036 ELE626020 UD15746SS 66-105-1 1011166 9.40113E+11 SND1262 1115594 4.6374.9 SSO60602.1 F042010582 66-105 131361 60-01-3514 SSD1361 ZM459 81011166 20309206OEVideo/Publications
1993773 1993861 1993741 1993862 1993742 1993732 1993831 1993744 1993701 1993702 1993707 1993729 1993829 1990499 1990332 1990331 1990330 1993771Add Your Number
