Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 202 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Center - Center (O.2) | 83 mm |
Mount Hole Center - Center (O.3) | 67 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 26.5 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | VALEO |
Voltage | 12 V |
Reference Information
0986029180 20479372OE STM1359 STV5833 AEY2544 31285513 220655 2269043 1685833 VAL438302 CST15273GS 30449R 3235 25-4216 6906262 438302 STRF482 12353 255117V 6N-11000-DA 88214456 LRS2544 458712 590.569.123.231 DS1775 PRSF482 36001082 UD19752S LRS02544 REAV6N-11000-DA 30659805 DRS0665 6015273.1 36002943 590.569.123.505 590.569.123.500 AV6N-11000-DA TS12E38Add Your Number
