Specifications
| Amp | 110 A |
| Bottom Mounting Foot Width (B) | 80 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 12 mm |
| Diameter (D.3) | 12 mm |
| Grooves | 2 qty |
| Groove Width (W.1) | 13 mm |
| Length (L.1) | 203 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 58 mm |
| Outside Diameter (O.D.2) | 88 mm |
| Plug Code | PL_5003 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 112 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAF | CF 75.310 9.2 | [PR228S] | 01.2001-05.2014 |
| DAF | CF 75 9.2 | [PR228S] | 01.2001-05.2013 |
| TEMSA | Tourmalin 12 9.2 | [PR228S] | 10.2006- |
| TEMSA | Tourmalin 13 9.2 | [PR228S] | 10.2006- |
| TEMSA | Tourmalin 9.2 | [PR228S] | 10.2006- |
Reference Information
CAL10645AS 160-55213 906.506.110.280 0124655037 LRA03247 1377860 20101546OE 8EL012584-481 0986085280 89213809 ALTS592 1697322R IA9476 2010645 19092015 554913RIB 20101546BN 72460252 63536550370 554919RIB 1697322 PRAF009 DRA0456 ALB1693 AAN5433 BOS0124655415 5610081 986085280 ALT1645 124655415 MAN2100 ALT10825 554919RI 115618 554913RI PRAS592 AG0002 0124655415 A24BH0100 ALT440 CAL10645GS 11.209.628 860809GB 115617 CA1693IR DA1566 2443 48-5859 MG819 ALT79881 ALTF009 2010645.1 UD101088A 21279N 8EL738053-001 LRA3247 124655037 442565 A24BH0100AS 19092007 DRA0456X 1697024 906.506.110.210 1697023 1977231 906.506.110.014 906.506.110.212 GA655003-AAdd Your Number
