Specifications
Amp | 55 A |
Bottom Mounting Foot Width (B) | 13.5 mm |
Diameter (D.1) | 8 mm |
Diameter (D.2) | 8 mm |
Diameter (D.3) | 8 mm |
Grooves | 1 qty |
Groove Width (W.1) | 9 mm |
Length (L.1) | 242 mm |
Mount Inside Length or Pad Mount C-C (C) | 80 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 50 mm |
Outside Diameter (O.D.2) | 75 mm |
Plug Code | PL_9105 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 41 mm |
Pulley Type | SOLID |
Unit Type | BOSCH |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BEDFORD | Blitz 2.3 D | [23D] | 01.1973-10.1987 |
OPEL | Omega A 2.3 D | [23YD] | 09.1986-03.1994 |
OPEL | Omega A 2.3 D | [23YD] | 10.1986-03.1994 |
OPEL | Omega A 2.3 TD | [23DTR] | 08.1988-03.1994 |
OPEL | Omega A 2.3 TD | [23DTR] | 09.1988-03.1994 |
OPEL | Omega A 2.3 TD | [23YDT] | 09.1986-08.1988 |
OPEL | Omega A 2.3 TD | [23YDT] | 10.1986-08.1988 |
OPEL | Rekord E 2.2 D | [23D] | 11.1982-08.1986 |
OPEL | Rekord E 2.2 TD | [23TD] | 06.1984-08.1986 |
OPEL | Rekord E 2.3 D | [23D] | 11.1982-08.1986 |
OPEL | Senator A 2.2 TD | [23TD] | 11.1984-08.1987 |
Reference Information
120488003 PRAF810 120488002 30383RI LRA01465 ALB0383 CA383IR UD100864A 440530 LRA1465 8EL725789-001 ANM36673 30383RIR EAA-241471 0120488003 0120488002 55675 28-1999 ALTF810Add Your Number
