Specifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 192 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 49 mm |
| Plug Code | PL_2801 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 33 mm |
| Pulley Type | CLUTCH |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| RENAULT | Grand Scenic 1.7 Blue DCi 120 | [R9N400] | 08.2018- |
| RENAULT | Grand Scenic 1.7 Blue DCi 120 | [R9N401] | 08.2018- |
| RENAULT | Grand Scenic 1.7 Blue DCi 150 | [R9N401] | 08.2018- |
| RENAULT | Kadjar 1.7 Blue DCi 150 | [R9N401] | 08.2018- |
| RENAULT | Kadjar 1.7 Blue DCi 150 4WD | [R9N401] | 08.2018- |
| RENAULT | Koleos 1.7 Blue DCi 150 | [R9N401] | 06.2019- |
| RENAULT | Megane 1.8 Blue DCi 150 | [R9N401] | 02.2019- |
| RENAULT | Megane 1.8 Blue DCi 150 Grandtour | [R9N401] | 02.2019- |
| RENAULT | Scenic 1.7 Blue DCi 120 | [R9N400] | 08.2018- |
| RENAULT | Scenic 1.7 Blue DCi 120 | [R9N401] | 08.2018- |
| RENAULT | Scenic 1.7 Blue DCi 150 | [R9N400] | 08.2018- |
| RENAULT | Scenic 1.7 Blue DCi 150 | [R9N401] | 08.2018- |
Reference Information
23100-5113R 40781 ALV3867 FG18T208 21523N LRA4540 21523-OS 575.976.180.501 LRA04540 FGN18T208 575.976.180.505 2017996AOE UD101064A 2015A69.1 23100-4742 FGN18T173 FG18T173 575.976.180.500 443312 28-8649 VALFG18T173 DRA2228 23100-4742R 2714141B CAL15A69GSAdd Your Number
