Specifications
| Amp | 200 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | 10.5 mm |
| Grooves | 4 qty |
| Length (L.1) | 195 mm |
| Mount Inside Length or Pad Mount C-C (C) | 69 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 59 mm |
| Pad mount thickness (E.1) | 20 mm |
| Pad mount thickness (E.2) | 20 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 77 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Mustang 2.3 EcoBoost | [C23HD0D] | 01.2015- |
| FORD | Mustang 2.3 EcoBoost | [C23HD0D] | 09.2017- |
| FORD | Mustang 2.3 EcoBoost | [N38H] | 01.2015- |
| FORD | Mustang 2.3 EcoBoost | [N48H] | 01.2015- |
| FORD | Mustang 2.3 EcoBoost | [N48H] | 07.2015- |
Reference Information
90-29-5898 2015272 GR3T-10300-FA GR3T-10300-FB FR3T-10300-FA ALN3916 104210-6910 27-8758 FR3Z-10346-F LRA4649 GR3Z-10346-K 595.303.200.050 DRA1930 556447RI LRA04649 104211-0760 104211-0761 GR3Z-10346-D UD101266AAdd Your Number
