Brand new AS-PL Alternator
STANDARD LINE
AS-PL
PRESTOLITE
Price:
NZ$ 1,421.56 including GST
NZ$ 1,236.14 excluding GST
or four payments of $355.39
with
Learn More
each
A9418S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
BLD3314GHSpecifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | 1/2" UNC 13 mm |
| Diameter (D.2) | 13 mm |
| Diameter (D.3) | 12 mm |
| Insulated Earth | Yes |
| Length (L.1) | 288 mm |
| Mount Inside Length or Pad Mount C-C (C) | 100.50 mm |
| OEM Product | No |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Type | No Pulley |
| Unit Type | PRESTOLITE |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DEMAG | H135S 28.0 | [VTA28] | 01.1990-12.1996 |
| DEMAG | H135S 28.0 | [VTA28] | 01.1997-12.1999 |
| DEMAG | H185S 38.0 | [KTTA38] | 01.1991-12.1992 |
| DEMAG | H285S 50.3 | [KTTA50] | 01.1988-12.1993 |
| KOMATSU | 730E 50.0 | [SSDA16V159] | 01.2008-12.2018 |
| KOMATSU | 730E-8 50.0 | [SSA16V159E] | 01.2014-12.2019 |
| KOMATSU | 830E-1AC 60.0 | [SDA16V160] | 01.2006-12.2012 |
| KOMATSU | 830E 60.0 | [QSK60] | 01.2005-12.2006 |
| KOMATSU | 860E-1K 60.0 | [SSDA16V160] | 01.2009-12.2021 |
| KOMATSU | 860E-1KT 60.0 | [SSDA16V160] | 01.2009-12.2021 |
| KOMATSU | 930E-4 60.0 | [SSDA16V160] | 01.2008-12.2012 |
| KOMATSU | 930E-4SE 78.0 | [SSDA18V170] | 01.2008-12.2012 |
| KOMATSU | 960E-1 78.0 | [SSDA18V170] | 01.2009-12.2013 |
| KOMATSU | 960E-1K 78.0 | [SSDA18V170] | 01.2011-12.2015 |
| KOMATSU | 960E-2 78.0 | [SSDA18V170] | 01.2011-12.2013 |
| KOMATSU | 960E-2K 78.0 | [SSDA18V170] | 01.2012-12.2013 |
| KOMATSU | 960E-2KT 78.0 | [SSDA18V170] | 01.2013-12.2015 |
| KOMATSU | H135S 28.0 | [VTA28] | 01.1997-12.1999 |
| KOMATSU | HD1500-7 50.0 | [SDA16V159E] | 01.2007-12.2018 |
| KOMATSU | PC3000-6 38.0 | [SDA12V159] | 01.2013-12.2013 |
| KOMATSU | PC3000-6 38.0 | [SSA12V159] | 01.2011-12.2012 |
Reference Information
| 032824 | DA SILVA |
| 0R5203 | CATERPILLAR |
| 1101001 | PRESTOLITE |
| 110805 | PRESTOLITE |
| 110806 | PRESTOLITE |
| 115386 | CARGO |
| 178217100 | PRESTOLITE |
| 20112936OE | REAL |
| 2011639.1 | SANDO |
| 23529789 | MTU |
| 240-40111 | ROBERT'S |
| 270-3314J | ROBERT'S |
| 2MJ4112P2 | MACK |
| 30000347 | CUMMINS |
| 3026259 | CUMMINS |
| 3604685RX | CUMMINS |
| 3675103RX | CUMMINS |
| 3975140 | CUMMINS |
| 4100763 | CUMMINS |
| 4372403 | CUMMINS |
| 448752 | LOGISTIK |
| 48-0636 | ELSTOCK |
| 4N3986 | CATERPILLAR |
| 500142604 | DRI |
| 5293213 | CUMMINS |
| 554938RI | KUHNER |
| 554938RIP | KUHNER |
| 61000853-12B1 | DELCO |
| 626.001.140.150 | PSH |
| 626.001.140.380 | PSH |
| 626.001.140.381 | PSH |
| 626.001.140.390 | PSH |
| 8600791 | DELCO |
| 8649N | WAI / TRANSPO |
| 8735N | WAI / TRANSPO |
| 90-05-9274N | WILSON |
| A134.373 | PSH |
| A146.388 | PSH |
| A9418S | AS-PL |
| ALP3314 | KRAUF |
| ALT136390 | SIOM |
| ALT42032 | WOODAUTO |
| ALTW014 | 3EFFE |
| BLD3314 | PRESTOLITE |
| BLD3314C | PRESTOLITE |
| BLD3314GH | PRESTOLITE |
| BLD3314HC | PRESTOLITE |
| BLD3315 | PRESTOLITE |
| BLD3315GH | PRESTOLITE |
| BLD3359GHMP | PRESTOLITE |
| BLD3365GH | PRESTOLITE |
| BLD3368 | PRESTOLITE |
| BLD3368GH | PRESTOLITE |
| BLD4108M | PRESTOLITE |
| CAL11639GS | CASCO |
| F032115386 | CARGO |
| G103507 | BTS TURBO |
| G103508 | BTS TURBO |
| LRA02419 | LUCAS |
| LRA2419 | LUCAS |
| PRAW014 | 3EFFE |
| PREBLD3314GH | WOODAUTO |
| UD21415A | AS-PL |
| WOOALT42032 | WOODAUTO |
| XA3023 | KOMATSU |
Video/Publications
