Specifications
| Kilowatt | 1.8 kW |
| Length (L.1) | 225 mm |
| Mount Hole Center - Center (O.1) | 130 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 14 qty |
| Pinion at Rest (B) | 53 mm |
| Rotation | ACW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DODGE | Caliber 2.2 CRD | [ENE] | 07.2010-11.2011 |
| JEEP | Compass 2.2 CRD | [ENE] | 05.2011- |
| JEEP | Compass 2.2 CRD 4x4 | [ENE] | 05.2011- |
| JEEP | Compass 2.2 CRD 4x4 | [OM651.925] | 12.2010- |
| JEEP | Patriot 2.2 CRD 4x4 | [ENE] | 01.2011-12.2017 |
Reference Information
04801830AC M001T23771 3264 M0T23771 UD90851S 15130103 K04801830AC 4801830AC 336114 STR5473 AEX1199 RL801830AC 25-5141 CST35308AS 88214934 CGB-55141 STR71350 M1T23771 CST35308GS 830.525.142.370 CGB-21158 MAV373080A M000T23771 107981 830.525.142.130 5035764 20437803BN M000T23771ZC LRS3979 M0T23771ZC S12MH0499A2 830.525.142.415 KRL801830AC 255003 M00T23771ZC 11040927 670022142 DRS1158 6035308.1 20437803OE 30399N S42007006 M1T23771ZC LRS03979 12423 STM2697 6035308Add Your Number
