Specifications
Kilowatt | 1.5 kW |
Length (L.1) | 227 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 10 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 33 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Civic 1.8 | [R18Z1] | 02.2012- |
HONDA | Civic 1.8 | [R18Z4] | 02.2012- |
HONDA | Civic 1.8 i-VTEC | [R18Z4] | 01.2014- |
HONDA | Civic 1.8 i-VTEC | [R18Z4] | 02.2012- |
HONDA | CR-V 2.0 AWD | [R20A6] | 10.2012- |
HONDA | CR-V 2.0 AWD | [R20A9] | 10.2012- |
HONDA | CR-V 2.0 i-VTEC | [R20A5] | 10.2012- |
HONDA | CR-V 2.0 i-VTEC | [R20A6] | 10.2012- |
HONDA | CR-V 2.0 i-VTEC | [R20A9] | 10.2012- |
Reference Information
31200-R3A-G01 428000-8130 STN7497 MAV422200A PYDU6 31200-R6F-G01 PYDU7 428000-8150 120.548.132.058 DRS0734 20432022BN 25-5049 256549R CST40220AS LRS03885 UD19722S 6040220 UD100728S 88214727Add Your Number
