Specifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 215 mm |
| Mount Hole Center - Center (O.1) | 84 mm |
| Mount Hole Center - Center (O.2) | 93 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| Mount Hole Diameter (C.3) | 9 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 20 mm |
| Rotation | CW |
| Spigot Diameter (A) | 68 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 114 1.5 D | (F20)[B37D15A] | 07.2015-06.2019 |
| BMW | 114 1.5 D | (F21)[B37D15A] | 06.2015- |
| BMW | 116 1.5 D | (F20)[B37D15A] | 03.2015-06.2019 |
| BMW | 116 1.5 D | (F21)[B37D15A] | 03.2015- |
Reference Information
UD18651S 20432885BN 210.574.123.050 210.574.123.058 6040588 31024-OS 3336 DRS1343 12418572918 12418572919 88215048 LRS4108 8572918 8572919 31024N 256184 STN2533 12429 MAV425880A 25-5271 CST40588AS 438000-1574 438000-1572 STR70594 438000-1571 LRS04108Add Your Number
