Specifications
| Kilowatt | 1.5 kW |
| Length (L.1) | 215 mm |
| Mount Hole Center - Center (O.1) | 91 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | M12x1.75 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 33 mm |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Civic 1.4 i-VTEC | [L13Z4] | 02.2012- |
| HONDA | Jazz 1.2 | [L12B1] | 07.2008- |
| HONDA | Jazz 1.3 i | [L13Z1] | 07.2008- |
| HONDA | Jazz 1.3 i | [L13Z2] | 07.2008- |
| HONDA | Jazz 1.4 | [L13Z1] | 11.2008- |
Reference Information
LRS3958 UD100729S 9913 120.554.132.058 428000-8110 LRS03958 PYDU4 STN2711 88214942 25-5120Add Your Number
