Specifications
Kilowatt | 1.9 kW |
Length (L.1) | 246.2 mm |
Mount Hole Center - Center (O.1) | 103 mm |
Mount Hole Center - Center (O.2) | 68 mm |
Mount Hole Center - Center (O.3) | 68 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | M10x1.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 3 qty |
No./Teeth | 13 qty |
Pinion at Rest (B) | 1.5 mm |
Rotation | CW |
Spigot Diameter (A) | 54 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LAND ROVER | Discovery Sport 2.2 D 4x4 | [224DT] | 09.2014- |
LAND ROVER | Range Rover Evoque 2.2 D 4x4 | [224DT] | 06.2011-12.2019 |
Reference Information
CGB-54423 12451 LR065819 STN0820 MAV424300 255403D LRS02750 6040430.1 UD100749S LRS2750 450.539.133.050 EJ32-11001-AD 88214752 20432034OE 450.539.133.058 DSN1365 EJ32-11001-AB EJ32-11001-AC STR70376 25-4423 CST40430GS LR047573 438000-0822 438000-0821 116246 438000-0820 LR084922 30595N 450.539.133.260 3747Add Your Number
