Specifications
Kilowatt | 1.3 kW |
Length (L.1) | 207 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 54 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
PORSCHE | 911 3.8 GT3 | [MA175] | 01.2013-12.2017 |
PORSCHE | 911 4.0 GT3 | [MA176] | 01.2015-12.2020 |
PORSCHE | 911 4.0 GT3 | [MDGGA] | 01.2015-12.2020 |
PORSCHE | 911 4.0 GT3 | [MDGGB] | 01.2018-12.2020 |
PORSCHE | 911 4.0 R | [MA176] | 01.2015-12.2016 |
PORSCHE | 911 4.0 Speedster | [MA177] | 01.2018-12.2020 |
PORSCHE | Boxster Spyder 3.8 | [MDBXA] | 01.2015- |
PORSCHE | Cayman 3.8 | [MDBXA] | 01.2015- |
Reference Information
480.518.102.260 DENDSN971 LRS04341 DSN971 16244N 428080-5780 428000-5780 9A1604104X 256820 25-5503 3366 LRS4341 256820D 9A160410400 UD100744SAdd Your Number
