Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 16 mm |
| Inside Diameter (I.D.1) | 25 mm |
| L.B+ | 17 mm |
| Length (L.1) | 68 mm |
| Outside Diameter (O.D.1) | 51.5 mm |
| Outside Diameter (O.D.2) | 45 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
060.001.094.830 ZM1996 1996 SSM1085 UD101123SSVideo/Publications
M000T39571ZC CK4T11000DA CK4Z11002A M0T39571ZC CK4T11000BA CK4Z11002C M000T39571 M000TD5571ZC M0TD5571ZC M0T39571Add Your Number
