Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 12 mm |
Inside Diameter (I.D.1) | 25 mm |
L.B+ | 15 mm |
Length (L.1) | 71.5 mm |
Outside Diameter (O.D.1) | 51.5 mm |
Outside Diameter (O.D.2) | 44.5 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Reference Information
UD101113SSVideo/Publications
M2T85772 M2T85771 M002T85771 M002T85772Add Your Number
