Associated Numbers
MN176300 M000T30872 M000T30871 M0T30872 M0T30871
Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 17 mm |
| Inside Diameter (I.D.1) | 25 mm |
| L.B+ | 17 mm |
| Length (L.1) | 64 mm |
| Outside Diameter (O.D.1) | 51.5 mm |
| Outside Diameter (O.D.2) | 44.5 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Reference Information
UD101122SSVideo/Publications
S5378S M0T15871 M000T16371 S5432S M000T15871 M0T16371Add Your Number
