Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 217 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 34 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Civic 1.8 i-VTEC | [R18Z4] | 01.2014- |
HONDA | Civic 1.8 i-VTEC | [R18Z4] | 02.2012- |
HONDA | CR-V 2.0 | [R20A9] | 10.2012- |
HONDA | CR-V 2.0 AWD | [R20A9] | 10.2012- |
Reference Information
63721642610 428080-8170 116426 UD816053(DENSO)S 20432525BN AEX1254 31200-R1P-H01 3711 120.597.092.260 LRS3953 120.597.092.058 31200-R1A-G51 MQS16426 DUDRL 88215160 DUDRK 428000-8170 STR6779 6040525 CST40525AS 25-5115 LRS03953 30488N PRSE446 DENDSN1492 DSN1492 120.597.092.050 MAV425250A J5214063 STRE446 STN8170Add Your Number
