Specifications
Kilowatt | 2.7 kW |
Length (L.1) | 297 mm |
Mount Hole Center - Center (O.1) | 113 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 13 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 15 mm |
Rotation | CW |
Spigot Diameter (A) | 90 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYSTER | Engine | [11DZ] | |
TOYOTA | 1Z-5 | [11DZ] | |
TOYOTA | F5 G10 FM 2.5 | [11DZ] |
Reference Information
190.534.112.310 190.534.112.058 190.534.112.415 28100-40291-71 3049479 228080-3711 CST40127AS 190.534.112.050 8076 28100-23660-71 DENDSN2112 2810023660 DRS0812 DSN2112 UD810304(DENSO)S LRS1447 25-2373 LRS01447 228000-3711 228000-3710 28100-40290-71 128000-0971 128000-0970 190.534.112.260 128000-0974 128000-0973 128000-0972 6040127 2810040291 2810040290 20432721BN 28100-23660Add Your Number
