Specifications
Kilowatt | 7.8 kW |
Length (L.1) | 300 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
Mount Hole Diameter (C.3) | 14 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 92 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 2384C | ||
CATERPILLAR | 2484C | ||
CATERPILLAR | 320D | ||
CATERPILLAR | 320D2 | ||
CATERPILLAR | 320D2-FM | ||
CATERPILLAR | 320D2-GC | ||
CATERPILLAR | 320D2-L | ||
CATERPILLAR | 320D-GC | ||
CATERPILLAR | 320D-L | ||
CATERPILLAR | 320E | ||
CATERPILLAR | 320E-L | ||
CATERPILLAR | 320E-LN | ||
CATERPILLAR | 320E-LRR | ||
CATERPILLAR | 320E-RR | ||
CATERPILLAR | 323D2 | ||
CATERPILLAR | 323D2-L | ||
CATERPILLAR | 323D-L | ||
CATERPILLAR | 323E-L | ||
CATERPILLAR | 323E-LN | ||
CATERPILLAR | 323E-SA | ||
CATERPILLAR | 323F | ||
CATERPILLAR | 323F-L | ||
CATERPILLAR | 324E | ||
CATERPILLAR | 324E-LN | ||
CATERPILLAR | 329D2 | ||
CATERPILLAR | 329D2-L | ||
CATERPILLAR | 329E | ||
CATERPILLAR | 329E-L | ||
CATERPILLAR | 329E-LN | ||
CATERPILLAR | 329F-L | ||
CATERPILLAR | 330D2 | ||
CATERPILLAR | 330D2-L | ||
CATERPILLAR | 330F | ||
CATERPILLAR | 330F-L | ||
CATERPILLAR | 330F-LN | ||
CATERPILLAR | 330F-MHPU | ||
CATERPILLAR | 330F-OEM | ||
CATERPILLAR | 335F | ||
CATERPILLAR | 335F-LCR | ||
CATERPILLAR | 538 | ||
CATERPILLAR | 548 | ||
CATERPILLAR | 558 | ||
CATERPILLAR | 559C | ||
CATERPILLAR | 579C | ||
CATERPILLAR | AP1000E | ||
CATERPILLAR | AP1000F | ||
CATERPILLAR | AP1055E | ||
CATERPILLAR | AP1055F | ||
CATERPILLAR | AP600F | ||
CATERPILLAR | AP655 | ||
CATERPILLAR | AP655F | ||
CATERPILLAR | AP655FL |
Reference Information
428080-9121 641.547.103.050 354-5671 641.547.103.261 88215254 STN7671 428000-9120 256002 428000-9121 30419N DSN2146 190-90137N UD816059(DENSO)S 190-90137 256002D 20R-4877 256002KAdd Your Number
