Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
Coil Bolt Length | 26 mm |
Inside Diameter (I.D.1) | 30 mm |
L.B+ | 26 mm |
Length (L.1) | 85 mm |
Outside Diameter (O.D.1) | 61 mm |
Outside Diameter (O.D.2) | 63.5 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 12 V |
Reference Information
MSX1770 UD813228(LETRIKA)SS MAHMSX1770KIT 72741337 054.900.010.310 16.916.221 MSX1770KITVideo/Publications
AZF4372 11132366 AZF4339 11132231Add Your Number
