Specifications
Kilowatt | 1.8 kW |
Length (L.1) | 232 mm |
Mount Hole Center - Center (O.1) | 43 mm |
Mount Hole Center - Center (O.2) | 164.5 mm |
Mount Hole Center - Center (O.3) | 133 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 22 qty |
Pinion at Rest (B) | 42 mm |
Rotation | ACW |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Avenger 2.0 CRD | [ECD] | 01.2007- |
DODGE | Caliber 2.0 CRD | [ECD] | 01.2006- |
JEEP | Compass 2.0 CRD | [ECD] | 01.2006- |
JEEP | Compass 2.0 CRD | [ECE] | 01.2006- |
JEEP | Patriot 2.0 CRD | [ECD] | 01.2006- |
JEEP | Patriot 2.0 CRD | [ECE] | 01.2006- |
MITSUBISHI | Grandis 2.0 DI-D | [BSY] | 01.2005- |
MITSUBISHI | Lancer 2.0 DI-D | [BKD] | 01.2008- |
MITSUBISHI | Lancer 2.0 DI-D | [BWC] | 01.2008- |
MITSUBISHI | Outlander 2.0 DI-D | [BSY] | 01.2007- |
Reference Information
M001T93371ZC 20437312BN 336028 PRSW442 RX033440AC 20437312OE LRS2253 S12MH0110 AEY2253 M001T93571 M1T93171ZC M001T93371 STRW442 M001T93171 114217 000986024710 220788 EAA-121947 M001T93571AM 33253N 6035213.1 STR71207 DRS0126 MTC158 M1T93071 S12MH0110A2 1810A143 05033440AC 9687 12132 05033440AA 1810A062 5033440AA 3C158 M1T93371ZC STR5236 5033440AC 986024710 CST35213GS 003-C158 MITM1T93571 CGB-20126 K05033440AC K05033440AA 101460M 150.555.223.370 25-3424 LRS02253 6035213 150.555.223.130 150.555.223.379 GST93371-A UD100067(MITSUBISHI)S M001T93171ZC 150.555.223.138 101460 130-10115NOE M001T93071 DRS0126N RAS31237 22.146 050033440AC CS1460 M1T93571AM CST35213AS J5215058 M1T93571 M1T93371 M1T93171Add Your Number
