Specifications
Kilowatt | 3.2 kW |
Length (L.1) | 258 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 83 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KUBOTA | Engine | [V3000] | |
KUBOTA | Engine 3.3 | [V3300] |
Reference Information
MAV376870 255993M MITM8T80874 691.508.092.265 M8T80872 M8T80871 M8T80874 M008T80874 PRSF645 6035687.1 M008T80871 M008T80872 255993 1K011-63012 M8T80872AM 1K011-63011 M008T80872AM 1K011-63013 1K011-63010 STR5408 STRF645 691.508.092.130 M008T80874AM M8T80874AM EAA-121169 691.508.092.370 243-22212 336414 18965N STR71103 20437786OE STM8871 CST35687GS UD100074(MITSUBISHI)SAdd Your Number
