Specifications
Kilowatt | 3.2 kW |
Length (L.1) | 259 mm |
Mount Hole Center - Center (O.1) | 121 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 22.5 mm |
Rotation | CW |
Spigot Diameter (A) | 95 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CASE | CX75SR 2.2 | [4LE2X] | 01.2008-12.2015 |
CASE | CX80 2.2 | [4LE2X] | 01.2008-12.2014 |
HITACHI | ZX75US-3 2.2 | [4LE2] | 01.2008-12.2014 |
HITACHI | ZX85USB-3 2.2 | [4LE2] | 01.2008-12.2014 |
JOHN DEERE | 75D 2.2 | [4LE2] | 01.2008-12.2014 |
JOHN DEERE | 85D 2.2 | [4LE2] | 01.2008-12.2014 |
KOBELCO | 70SR | [4JG1] | 01.2011-12.2013 |
KOBELCO | 75SR | [4LE2X] | 01.2012-12.2014 |
KOBELCO | 80CS | [4JB1] | 01.2002-12.2009 |
KOBELCO | SK70SR-2 | [4LE2X] | 01.2010-12.2013 |
KOBELCO | SK75SR | [4LE2X] | 01.2013-12.2015 |
KOBELCO | SK80CS-2 | [4JB1] | 01.2002-12.2009 |
KOBELCO | SK80CS-2 | [4LE2X] | 01.2010-12.2013 |
KOBELCO | SK85CS-3E | [4LE2X] | 01.2013-12.2016 |
NEW HOLLAND | E135B | [D04FR(94HP)] | 01.2008-12.2015 |
NEW HOLLAND | E70B | [4LE2X] | 01.2008-12.2012 |
NEW HOLLAND | E80B | [4LE2X] | 01.2008-12.2012 |
Reference Information
130-80174 STR600039 CST35712GS M008T80371 M008T80372 M008T80373 M008T80374 71434500 M8T80373 8972047190 M8T80374 254344M 8972047191 M8T80371 254344 M8T80372 19545N STM1571 8971374782 8971374780 8971374781 8980723150 243-22213 8980723151 131.521.112.370 AI-80093 M8T81571AM M008T81571 130-80174NOE 131.521.112.130 6035712.1 115802 20437217OE MITM8T81571 UD100979(MITSUBISHI)S S-80617 91-27-3515 M008T81571AM M8T81571 STR71329 130-80174N MAV377120Add Your Number
