Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 207 mm |
Mount Hole Center - Center (O.1) | 106 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 14 qty |
Pinion at Rest (B) | 18 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DOOSAN | DX15 1.0 | [L3E] | 01.2009- |
DOOSAN | DX18 1.0 | [L3E] | 01.2009- |
DOOSAN | Solar 015 1.0 | [L3E] | 01.2002-12.2008 |
DOOSAN | Solar 018-VT 1.0 | [L3E] | 01.2004-12.2008 |
Reference Information
8310 20437372OE CST35273GS UD100963(MITSUBISHI)S 2.401-00003 130-00105 M000T60481 M000T60482 25-4413 114696 MITM0T60482 MITM0T60481 88214774 6035273.1 30L66-20600 CGB-54413 M0T60481 M0T60482 M0T60481AM 30L66-10600 M0T60482AM LRS02740 M000T60482AM M000T60481AM 150.571.142.130 150.571.142.370 MD072585 2.401.00003 LRS2740Add Your Number
