Specifications
Kilowatt | 5 kW |
Length (L.1) | 288 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 127 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Various Models |
Reference Information
20437907OE M008T64671 5362464RX 701.537.123.370 M008T64672 M8T64671AM M8T64671A M8T64672AM MITM8T64671 CST35709GS 6035709.1 UD21290(MITSUBISHI)S M008T64671A M8T64672 M8T64671 5362464 M008T64672AM M008T64671AM 536246400RXAdd Your Number
